$70-450 /piece
| Tipo di pagamento: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,PayPal |
| Incoterm: | FOB,CIF,EXW |
| Quantità di ordine minimo: | 1 piece |
| Trasporti: | Ocean,Land,Air |
| Porta: | Shanghai |
marchio: Libra
Standard Or Nonstandard: Standard
Body Material: 45# steel
Place Of Origin: Taizhou City, Jiangsu Province, China
Color: Customized
Warranty: 1 Year
Cylinder Capacity: 100 Ton
Maximum Stroke: 56mm
Closed Height: 141mm
Certificati : ISO9001:2008/CE
Brand Name: JOBA
Supporta La Personalizzazione: OEM
Place Of Origin: Jiangsu, China
| Unità vendibili | : | piece |
| Tipo pacchetto | : | Scatola di legno |
The file is encrypted. Please fill in the following information to continue accessing it
|
Model Number |
Cylinder Capacity (T) |
Stroke (mm) |
Body Height (mm) |
Cylinder
Out Dia |
Hydraulic Tank Capacity (cm³) |
Piston Diameter (mm) |
Weight (kg) |
| JRCS-51 | 5T | 24 | 72 | 45 | 15 | 27 | 1.4 |
| JRCS-101 | 10T | 38 | 88 | 69 | 55 | 38.1 | 4.1 |
| JRCS-201 | 20T | 45 | 99 | 92 | 129 | 50.8 | 5 |
| JRCS-302 | 30T | 60 | 118 | 101 | 261 | 66.5 | 6.8 |
| JRCS-502 | 50T | 60 | 122 | 124 | 373 | 69.8 | 12 |
| JRCS-1002 | 100T | 56 | 141 | 165 | 722 | 92.2 | 23 |
| JRCS-1502 | 150T | 56 | 160 | 205 | 900 | 114 | 53 |
| JRCS-2002 | 200T | 56 | 168 | 271 | 1120 | 138 | 65.8 |
| Product LOGO: | Customized LOGO As Required |
| MOQ: | 1 piece |
| Shipping: | By Sea By Air & Express Delivery |
| Packing: | Carton Box,Plywood Case,Customized |
| Sample Avaliability: | Yes |
| OEM: | Accept |
| Delivery Details: | 10 Days After Total Payment |
| Trade Terms: | FOB ,CIF, EXW |
| Pay Terms: | T/T.Western union, Paypal, L/C |
